Product Description:
The IP65 rating of these road led lights ensures that they are
dust-tight and protected against water jets. They are suitable for
use in all weather conditions, making them ideal for outdoor
spaces.
Our Outdoor LED Street Lights are available in customized RAL
colors such as gray, black, and white, allowing you to choose the
color that best suits your aesthetic preferences. The LED SMD light
source ensures that the lights are energy-efficient and provide
bright illumination at all times.
The adjustable bracket street light housing allows you to adjust
the angle of the light to suit your needs. The 120° beam angle
ensures that the light is spread over a wide area, providing
maximum coverage and visibility.
Our Outdoor LED Street Lights are easy to install and require
minimal maintenance. They are designed to last for a long time and
provide reliable lighting solutions for roads and streets. So,
whether you are looking to light up a residential street or a busy
highway, our Outdoor LED Street Lights are the perfect solution for
you.
Features:
- Product Name: Outdoor LED Street Lights
- Warranty: 3-5 Years
- Color Temperature: 3000K-6000K
- Application: Main Road High Way Flyover City Street Overpass
Sidewalk Square School Residential District Industrial Area Park
- IP Rating: IP65
- Lifespan: 50,000 Hours
- Smart outdoor lights
- Street LED lamps
- Diecast shell body
Technical Parameters:
Product Specifications
Below are the specifications for our YASL series LED street lights:
| Product Code | YASL-35-40(M) | YASL-35-60(M) | YASL-35-100(M) | YASL-35-150(M) | YASL-35-240(M) |
| Input Wattage(W) | 30-50 | 50-80 | 60-120 | 120-200 | 200-320 |
| Number of lenses(PCS) | 4 | 6 | 9 | 15 | 24 |
| Product Size(m m) | 563x215x110 | 613x240x110.2 | 654x256x114 | 780x287x114 | 834x341x114 |
| Packing Size(m m) | 610x250x260 | 660x280x260 | 710x300x260 | 810x330x260 | 860x380x260 |
| Net Weight (kgs) | 2.2 | 2.6 | 3.1 | 4 | 5.5 |
| Gross Weight (kgs) | 4.9 | 5.7 | 6.7 | 8.5 | 11.5 |
| Quantity of packing (pcs) | 2 | 2 | 2 | 2 | 2 |
| Installation Height (m) | 3～8 | 4～8 | 6～10 | 8～12 | 8～14 |
| Installation Pipe Diameter | 60 | 60 | 60 | 60 | 60/76 |
| adjustable angle | ±15°Adjustable |
| Materials | Housing:ADC12;Cover:Toughened Glass；Screws:304stainless screws |
| Spray colors | Double Grey；Sandy Black；Matt Silver |
| Led Specifications | 3030,5050(Optional) |
| Optical effect | 130～190 lm/w(Optional) |
| Color Temperature | 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference:Energy
Star) |
| color rendering index | Ra≥70；Ra≥80；Ra≥90(Optional) |
| Optics | TYPEI,TYPEII,TYPEIII,TYPEV,TYPEIV(Optional) |
| Driver brand | as your request |
| Input Voltage | AC90～305V |
| Security level | ClassI/ClassII/Class1/Class2(Optional) |
| Frequency Range | 50/60Hz |
| Power Factor | PF≥0.95 |
| Protection | Overcurrent/Short circuit/Over temperature |
| Dimming mode | Time control/0-10V/ Opticalcontrol/Microwaves/DALI(Optional) |
| Lightning protection | 10KV/15KV/20KV(Optional) |
| Working conditions Range | -40 to 45℃,20% to 90%RH |
| Warranty | 5/8 year(Optional) |
| Protection level | IP66;GlassIK08/09/10(Optional),Lamp shell IK08. |
| Certifications | ENEC;CE;CB;IEC;RoHs;TUV;Lightning protection;LM-79;LM-80;IP66 |
Applications:
The YASL-35 model has a high efficiency of 130-190lm/w, providing
bright and energy-saving lighting for any occasion. With an input
voltage of AC85-265V and a color temperature range of 3000K-6000K,
these street lights can be customized to meet specific lighting
needs.
These LED street lights are certified with CE, EMC, LVD, and ENEC,
ensuring they meet industry standards for quality and safety. They
are available for purchase in quantities as low as 1pc, with a
price range of US$19.3 - US$42.3 per unit. The packaging details
include 1pc per carton and a delivery time of 7-5 days.
The adjustable bracket street light housing makes it easy to
install and adjust the lighting angle, making it suitable for main
roads, highways, flyovers, city streets, overpasses, sidewalks,
squares, schools, residential districts, industrial areas, and
parks.
These street LED lamps are designed to provide long-lasting and
energy-efficient lighting that is ideal for outdoor use. With a
supply ability of 10,000pcs per month and payment terms of TT, it
is easy to purchase these high-quality street lights from
Die-casting Man in Ningbo, China.
FAQ:
Q1: What is the brand name of these outdoor LED street lights?
A1: The brand name of these street lights is Die-casting Man.
Q2: What is the model number of these outdoor LED street lights?
A2: The model number of these street lights is YASL-35.
Q3: Where are these outdoor LED street lights manufactured?
A3: These street lights are manufactured in Ningbo, China.
Q4: What certifications do these outdoor LED street lights have?
A4: These street lights are certified with CE, EMC, LVD, and ENEC.
Q5: What is the minimum order quantity for these outdoor LED street
lights?
A5: The minimum order quantity for these street lights is 1PC.
