Product Description:
The diecast shell body of the light ensures that it is sturdy and
durable, and can withstand even the harshest weather conditions.
The LED technology used in these lights ensures that they have a
long lifespan of up to 50,000 hours, which means that they will
last for years without needing to be replaced. Additionally, the
lights have a color temperature range of 3000K-6000K, allowing you
to choose the perfect lighting for your specific needs.
These public lamp LED lights are also designed to work in a wide
range of temperatures, from as low as -40℃ to as high as 50℃. This
means that they can be used in a variety of environments, from cold
winter nights to hot summer days.
In conclusion, the Outdoor LED Street Lights are a reliable and
efficient lighting solution for a variety of outdoor applications.
With their diecast shell body, long lifespan, and wide range of
color temperature and working temperature, they are a must-have for
anyone in need of high-quality outdoor lighting.
Features:
- Product Name: Outdoor LED Street Lights
- Application:
- Main Road
- High Way
- Flyover
- City Street
- Overpass
- Sidewalk
- Square
- School
- Residential District
- Industrial Area
- Park
- Power: 30W - 150W - 300W
- Working Temperature: -40℃~50℃
- Warranty: 3-5 Years
- Color: Customized Ral. No. Such As Gray, Black, White
- Features:
- Smart outdoor lights
- LED light housing outdoor lighting
- Diecast shell body
Technical Parameters:
Product Specifications
| Product Code | YASL-35-40(M) | YASL-35-60(M) | YASL-35-100(M) | YASL-35-150(M) | YASL-35-240(M) |
| Input Wattage(W) | 30-50 | 50-80 | 60-120 | 120-200 | 200-320 |
| Number of lenses(PCS) | 4 | 6 | 9 | 15 | 24 |
| Product Size(m m) | 563x215x110 | 613x240x110.2 | 654x256x114 | 780x287x114 | 834x341x114 |
| Packing Size(m m) | 610x250x260 | 660x280x260 | 710x300x260 | 810x330x260 | 860x380x260 |
| Net Weight (kgs) | 2.2 | 2.6 | 3.1 | 4 | 5.5 |
| Gross Weight (kgs) | 4.9 | 5.7 | 6.7 | 8.5 | 11.5 |
| Quantity of packing (pcs) | 2 | 2 | 2 | 2 | 2 |
| Installation Height (m) | 3～8 | 4～8 | 6～10 | 8～12 | 8～14 |
| Installation Pipe Diameter | 60 | 60 | 60 | 60 | 60/76 |
| adjustable angle | ±15°Adjustable |
| Materials | Housing:ADC12;Cover:Toughened Glass；Screws:304stainless screws |
| Spray colors | Double Grey；Sandy Black；Matt Silver |
| Led Specifications | 3030,5050(Optional) |
| Optical effect | 130～190 lm/w(Optional) |
| Color Temperature | 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference:Energy Star) | | | | |
| color rendering index | Ra≥70；Ra≥80；Ra≥90(Optional) |
| Optics | TYPEI,TYPEII,TYPEIII,TYPEV,TYPEIV(Optional) |
| Driver brand | as your request |
| Input Voltage | AC90～305V |
| Security level | ClassI/ClassII/Class1/Class2(Optional) |
| Frequency Range | 50/60Hz |
| Power Factor | PF≥0.95 |
| Protection | Overcurrent/Short circuit/Over temperature |
| Dimming mode | Time control/0-10V/ Opticalcontrol/Microwaves/DALI(Optional) |
| Lightning protection | 10KV/15KV/20KV(Optional) |
| Working conditions Range | -40 to 45℃,20% to 90%RH |
| Warranty | 5/8 year(Optional) |
| Protection level | IP66;GlassIK08/09/10(Optional),Lamp shell IK08. |
| Certifications | ENEC;CE;CB;IEC;RoHs;TUV;Lightning protection;LM-79;LM-80;IP66 |
Applications:
The adjustable bracket street light housing allows for easy
installation and positioning, making it versatile and adaptable to
any outdoor lighting need. These LED street lights are made with
die-casting aluminum material which ensures durability and
longevity in harsh weather conditions.
These outdoor LED street lights have a color temperature range of
3000K-6000K, providing a bright and clear light source. The CRI of
>70 ensures that the colors of objects are accurately
represented, making it perfect for outdoor security and
surveillance systems.
The Die-casting Man YASL-35 Outdoor LED Street Lights are certified
with CE, EMC, LVD, and ENEC certifications. They have a minimum
order quantity of 1PC and a price range of US$19.3 - US$42.3,
making it affordable for small to large-scale outdoor lighting
projects. The packaging details include 1PC/CTN and a delivery time
of 7-5DAYS. The payment terms are TT, and the supply ability is
10000PCS/M.
Overall, the Die-casting Man YASL-35 Outdoor LED Street Lights are
a reliable, energy-efficient, and cost-effective solution for a
wide range of outdoor lighting needs.
FAQ:
Q1: What is the brand name of these outdoor LED street lights?
A1: The brand name of these street lights is Die-casting Man.
Q2: What is the model number of these outdoor LED street lights?
A2: The model number of these street lights is YASL-35.
Q3: Where are these outdoor LED street lights manufactured?
A3: These street lights are manufactured in Ningbo, China.
Q4: What certifications do these outdoor LED street lights have?
A4: These street lights are certified by CE, EMC, LVD, and ENEC.
Q5: What is the minimum order quantity for these outdoor LED street
lights?
A5: The minimum order quantity for these street lights is 1 piece.
Q6: What is the price range of these outdoor LED street lights?
A6: The price range of these street lights is between US$19.3 to
US$42.3 per piece.
Q7: How are these outdoor LED street lights packaged for shipment?
A7: These street lights are packaged in 1 piece per carton.
Q8: What is the delivery time for these outdoor LED street lights?
A8: The delivery time for these street lights is 7-5 days.
Q9: What are the payment terms for these outdoor LED street lights?
A9: The payment terms for these street lights are TT.
Q10: What is the supply ability of these outdoor LED street lights?
A10: The supply ability of these street lights is 10000 pieces per
month.
