Brand Name : | Die-casting Man |
Model Number : | YASL-35 |
Certification : | CE. EMC, LVD, ENEC |
Price : | US$19.3 - US$42.3 |
Delivery Time : | 7-5DAYS |
Payment Terms : | TT |
Supply Ability : | 10000PCS/M |
With an efficiency range of 130-190lm/w, our high lumen LED street
light energy saving technology offers bright and clear lighting,
while also reducing energy consumption and costs. The CRI (Color
Rendering Index) of our outdoor LED street lights is >70,
providing accurate and vibrant colors for your outdoor environment.
Our Outdoor LED Street Lights come with a 3-5 year warranty,
ensuring customer satisfaction and peace of mind. With a lifespan
of 50,000 hours, our LED street lights are guaranteed to last for
years to come, eliminating the need for constant replacements and
maintenance.
In addition to its high-quality performance, our Outdoor LED Street
Lights are customizable in color with a variety of RAL options such
as gray, black, and white. This allows for a seamless integration
into any outdoor environment, while maintaining a sleek and modern
design.
Overall, our Outdoor LED Street Lights are an excellent choice for
anyone looking to illuminate their outdoor spaces with high
efficiency, long-lasting performance, and customizable design.
Looking for a high power outdoor lamp that is energy efficient and cost effective? Check out our Outdoor LED Street Lights! With a wide beam angle of 120° and a CRI rating of over 70, these lights provide bright and clear illumination. The IP65 rating ensures they are protected against dust and moisture, making them ideal for outdoor use. Invest in these LED street lights for a long-lasting and eco-friendly lighting solution.
The following product codes are available:
This product is available in various input wattages, number of lenses, sizes, and weights:
Product Code | YASL-35-40(M) | YASL-35-60(M) | YASL-35-100(M) | YASL-35-150(M) | YASL-35-240(M) |
Input Wattage(W) | 30-50 | 50-80 | 60-120 | 120-200 | 200-320 |
Number of lenses(PCS) | 4 | 6 | 9 | 15 | 24 |
Product Size(m m) | 563x215x110 | 613x240x110.2 | 654x256x114 | 780x287x114 | 834x341x114 |
Packing Size(m m) | 610x250x260 | 660x280x260 | 710x300x260 | 810x330x260 | 860x380x260 |
Net Weight (kgs) | 2.2 | 2.6 | 3.1 | 4 | 5.5 |
Gross Weight (kgs) | 4.9 | 5.7 | 6.7 | 8.5 | 11.5 |
Quantity of packing (pcs) | 2 | 2 | 2 | 2 | 2 |
Installation Height (m) | 3~8 | 4~8 | 6~10 | 8~12 | 8~14 |
Installation Pipe Diameter | 60 | 60 | 60 | 60 | 60/76 |
adjustable angle | ±15°Adjustable | ||||
Materials | Housing:ADC12;Cover:Toughened Glass;Screws:304stainless screws | ||||
Spray colors | Double Grey;Sandy Black;Matt Silver | ||||
Led Specifications | 3030,5050(Optional) | ||||
Optical effect | 130~190 lm/w(Optional) | ||||
Color Temperature | 2700K,3000K,3500K,4000K,5000K,5700K,6500K(Optional)(Reference:Energy Star) | ||||
color rendering index | Ra≥70;Ra≥80;Ra≥90(Optional) | ||||
Optics | TYPEI,TYPEII,TYPEIII,TYPEV,TYPEIV(Optional) | ||||
Driver brand | as your request | ||||
Input Voltage | AC90~305V | ||||
Security level | ClassI/ClassII/Class1/Class2(Optional) | ||||
Frequency Range | 50/60Hz | ||||
Power Factor | PF≥0.95 | ||||
Protection | Overcurrent/Short circuit/Over temperature | ||||
Dimming mode | Time control/0-10V/ Opticalcontrol/Microwaves/DALI(Optional) | ||||
Lightning protection | 10KV/15KV/20KV(Optional) | ||||
Working conditions Range | -40 to 45℃,20% to 90%RH | ||||
Warranty | 5/8 year(Optional) | ||||
Protection level | IP66;GlassIK08/09/10(Optional),Lamp shell IK08. | ||||
Certifications | ENEC;CE;CB;IEC;RoHs;TUV;Lightning protection;LM-79;LM-80;IP66 |
Other technical specifications include:
The LED light housing is designed to withstand harsh outdoor
conditions, ensuring long-lasting and reliable performance. With an
IP65 rating, these lights are protected from dust, water, and other
environmental elements, making them ideal for use in any climate.
These outdoor LED street lights are certified by CE, EMC, LVD, and
ENEC, ensuring that they meet the highest standards for quality and
safety. They are also available in a range of colors, including
customized Ral. No. options such as gray, black, and white.
With a minimum order quantity of just one piece, these LED street
lights are accessible to a variety of customers. The prices for the
YASL-35 model range from US$19.3 to US$42.3, making them an
affordable option for any budget.
Die-casting Man's outdoor LED street lights have a supply ability
of up to 10,000 pieces per month, and a delivery time of just 7-5
days. Payment terms are TT, and the warranty for these lights is
3-5 years, ensuring that customers can have peace of mind with
their purchase.
These LED street lights have an input voltage of AC85-265V and a
CRI of over 70, providing bright and clear lighting for any outdoor
area. Whether you need to illuminate a city street or a small
alley, these LED lights are the perfect solution for your outdoor
lighting needs.
Q1: What is the brand of Outdoor LED Street Lights?
A1: The brand name of the product is Die-casting Man.
Q2: Where is the product made?
A2: The Outdoor LED Street Lights are made in Ningbo, China.
Q3: What certifications does the product have?
A3: The product is certified with CE, EMC, LVD, and ENEC.
Q4: What is the minimum order quantity for the product?
A4: The minimum order quantity for the product is 1 piece.
Q5: What is the price range of the product?
A5: The price range of the product is between US$19.3 - US$42.3.
Q6: What are the packaging details for the product?
A6: The packaging details for the product is 1 piece per carton.
Q7: What is the delivery time for the product?
A7: The delivery time for the product is between 7-5 days.
Q8: What are the payment terms for the product?
A8: The payment terms for the product is TT (Telegraphic Transfer).
Q9: What is the supply ability of the product?
A9: The supply ability of the product is 10000 pieces per month.
![]() |
