Product Specification:
SL-29 series LED street lights provide complete lighting solutions
for road and street.
Compliance with international standards ENEC, CB, CE, EMC, LM79,
Rohs …
Full wattage from 30 to 300W, with ultra-high luminous efficiency
and various lighting distribution
Intelligent control system: timing dimming, 0-10v dimming, Dali,
Zigbee, NB-Lot, etc
Class I or ClassII both availble.
| Model | SL-29-40 | SL-29-60 | SL-29-100 | SL-29-160 | SL-29-240 |
| Input Wattage (W) | 30/40/50/60 | 50/60/70/80/90 | 80/90/100/120/150 | 150/160/180/200 | 200/240/260/300 |
| Installation Pipe Diameter | φ45/φ60mm | φ45/φ60mm | φ45/φ60mm | φ45/φ60mm | φ45/φ60mm |
| Installation Height (m) | 3-6 | 4-8 | 6-10 | 8-14 | 12-14 |
| Input Voltage | 90~305Vac |
| Frequency Range | 50/60Hz |
| Power Factor | ≥0.9 |
| Light source | LED |
| Driver | Inventronics |
| Meanwell (optional) |
| other brand of driver(upon request) |
| Luminaire efficacy (lm/W) | 130-190 |
| Color Temperature | 4000K (3000K/5000K,5700K upon request) |
| Color rendering index | ≥70 |
| Diming | Dali (optional) |
| 1-10V (optional) |
| PWM (optional) |
| Smart control management system (upon request) |
| The environment temperature | -40～45℃ |
| Humidity of Working Condition | 20%～90%RH |
| Protectin Grade | IP66 |
| Protection level | IK08 |
| Standards & Certifications | ENEC(uncertificated) |
| CB(uncertificated) |
| CE(uncertificated) |
| Rohs(uncertificated) |
| Options | Photocell |
| Surge protection |
| External cable (length upon request) |
| Smart control device |
| Meterials | Housing: ADC12 die-cast aluminum |
| Cover: Toughened Glass |
| External Screws: 304 stainless screws |
| Color | Grey/Black ( other upon request) |
Applications:
Introducing Die-casting Man's YASL-29 High Power LED Street Light,
the perfect fit for Hot Sale Energy Saving Dali Parking Garage
Luminaires. With its 600*300*80mm size, this LED street light is
ideal for installation height COB LED Street Light applications.
Constructed from durable aluminum alloy, the YASL-29 is built to
withstand the test of time and provide long-lasting illumination.
With a lifespan of 50,000 hours and a color temperature of
3000-6500K, this LED light is sure to make your Hot Sale Energy
Saving Dali Parking Garage Luminaires shine, and with a warranty of
3 years, you can rest assured knowing your investment is well
protected. Get your High Power LED Street Light from Die-casting
Man today and experience the difference!
Customization:
Customized Service for High Power LED Street Light
Brand Name: Die-casting Man
Model Number: YASL-29
Place of Origin: Ningbo, China
CRI: Ra>80
Beam Angle: 120°
Power: 100W
Material: Aluminum Alloy
Size: 600*300*80mm
