Energy Saving Road Lighting Fixtures 50w structure back radiating rib

Ask Lasest Price
Brand Name :	Die Casting Man
Model Number :	SL-09-50
Certification :	CE
Price :	Negotiation
Payment Terms :	By T/T 30% in advance and 70% after shipment EXW/FOB NINGBO,Western Union,L/C
Supply Ability :	10000PCS/Month.
Delivery Time :	7-30 days base on order quantity

Add to Cart

Product Details
Company Profile

Energy Saving Road Lighting Fixtures 50w structure back radiating rib

Outdoor Street Lamps and Parking Lot Lighting | Die casting man
Type of Protection: IP 66
Protection Class: II
Impact Protection: IK08 /IK10
Features:
Self-cleaning structure design of back radiating rib；
Adjustable Mounting Direction and angle ± 10 °；
Dimming:Time control/0-10V/ Optical control // DALI dimming
Lightning protection:10KV/15KV/20KV;
Protection level:
Water resistance Rating: IP66；
Impact Protection Rating : IK08/09/10；
Optical effect:130～170 lm/W；
Warranty:5/8 year option.
IP66 CE RoHS

Product Specification

Product code	YASL-09-30	YASL-09-50	YASL-09-100	YASL-09-150
Input Wattage	40W	60W	120W	250W
Color Temperature	2700～6500K	2700～6500K	2700～6500K	2700～6500K
Luminous Flux	5200-6000lm	7800-9000lm	15600-18000lm	32500-37500lm
Input Voltage	AC90～305V	AC90～305V	AC90～305V	AC90～305V
Frequency Range	50/60Hz	50/60Hz	50/60Hz	50/60Hz
Power Factor	PF≥0.95	PF≥0.95	PF≥0.95	PF≥0.95
Color rendering index	Ra≥70	Ra≥70	Ra≥70	Ra≥70
Temperature of Working Condition	-40～50℃	-40～50℃	-40～50℃	-40～50℃
Humidity of Working Condition	20%～90%RH	20%～90%RH	20%～90%RH	20%～90%RH
LED Lifetime	50000h	50000h	50000h	50000h
Protectin Grade	IP66	IP66	IP66	IP66
Protection level	IK08/09/10	IK08/09/10	IK08/09/10	IK08/09/10
Installation Pipe Diameter	φ45/60mm	φ45/60mm	φ45/60mm	φ60/76mm
Installation Height	3-6m	4-8m	8-12m	10-14m
Net Weight	2.7kgs	4.0kgs	6.5kgs	12.8kgs
Gross Weight	3.0kgs	4.5kgs	7.0kgs	13.2kgs
Packing Size(m m)	560265145	700350160	700350160	910415195

Product Size
Model	YASL-09-30	YASL-09-50	YASL-09-100	YASL-09-150
L(mm)	455	530	736	846
W(mm)	180	230	292	367
H(mm)	95	105	112	134

INSTALL.
This fixture is mounted on a 3-14m in pole. lnstalling Ways Both
Horizontal and Vertical available and adjustable angle-15°to+15°
ENERGY SAVINGS.
High efficiency By illuminating your area with modern LED
technology, you get a significant reduction in energy costs as well
as superior light quality.
Compared to metal halide lamps ,the average savings obtanined using
LED Lighting is approx 70% ,90% to halogen lamps .
This fixture provides a lumen output equal to 400 Watt Metal Halide
and can reduce your lighting bill when
compared to metal halide and hps lighting.

WARRANTY / CERTIFICATIONS.
LED Lighting Supply provides a 5 year warranty along with CE and
Rebate Eligible certifications.

Details Images
