    outdoor area lighting led 180w IP66 6000k industrial led street light fixtures

    Ask Lasest Price
    Brand Name : die-casting man
    Model Number : ZHSL-14-100
    Certification : CE ROHS TUV
    Price : USD44.00/PCS
    Supply Ability : 30pcs/per day
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    outdoor area lighting led 180w IP66 6000k industrial led street light fixtures

    Product CodeYASL-14-40YASL-14-80YASL-14-120
    Input Wattage40W80W150W
    Color Temperature3000-6500K3000-6500K3000-6500K
    Luminous Flux4400-5000lm9200-10400lm16500-18750lm
    Input VoltageAC90-305VAC90-305VAC90-305V
    Frequency Range50/60Hz50/60Hz50/60Hz
    Power FactorPF≥0.95PF≥0.95PF≥0.95
    color rendering indexRa≥70Ra≥70Ra≥70
    Temperature of Working Condition-40-50℃-40-50℃-40-50℃
    Humidity of Working Condition20%-90%RH20%-90%RH20%-90%RH
    LED Lifetime50000h50000h50000h
    Protection GradeIP66IP66IP66
    Installation Pipe Diameter⌀60mm⌀60mm⌀70mm
    Installation Height4-7m6-10m8-12m
    Net Weight4.6kg6.0kg9.8kg
    Gross Weight5.0kg6.5kg10.6kg
    Packing Size(mm)660×315×185770×315×185800×290×400

    50~180W Outdoor LED Street Light /Area Light Aluminum Die-Casting housing NEW DESIGN


    Specifications


    Model NumberZHSL-14-100
    Electrical Specifications

    Frequency Range

    50/60Hz
    Input Wattage50W 100W 120W
    Input VoltageAC90-305V
    Operating Humidity20%~90%RH
    Working Temperature-40 ~ 50°C
    Power Fact(PF)>0.95
    Driver Efficiency> 0.9
    Photometric SpecificationsLED Luminous Flux8400~9600 lm
    Power FactorPF≥0.92
    Led Luminous Efficiency>100LM/W
    CRIRa ≥ 70
    Color Temperature3000/4000/6500k
    Mechanical SpecificationsIP RatingIP66
    Warranty3Years
    Heat Radiatordie-casting body as heat sink
    LensPatented anti-glare optic lense
    Fixture Dimension738X289X116 MM
    Fixture Weight5.4 KG

    Packing Information

    Packing Type1 unit /ctn
    Packing Dimension795X340X125 mm
    Packing Weight6.5 KG

    LED Engine Module

    · LED life time of 50,000hours

    · High power integrated packaging LED chips, 120° beam spread available

    · Minimum CRI of 70, custom CRI available

    · Operating temp: -40º C to +50º C

    · No toxic chemicals / ROHS compliant

    · Low Tj for long life, low lumen depreciation

    · CE certified, meets ROHS standards

    · Eligible for Rebates, Design Lights Consortium® Qualified

    · 50-80% energy savings

    · Manufactured in the China

    · Standard distribution is Type V, others distributions available

    Electrical

    · Standard AC input of 90-305V,up to 480v available

    · EMI filter: 47CFR, part 2, part 15

    · Power factor: >0.9

    · Total harmonic distortion: <20%

    · Surge protection: IEC/EN 61000-4-5 EMC test standard

    · Licensed electrician required for installation

    Housing

    · Rugged, fully sealed, die-cast aluminum housing

    · UV-resistant, multi-layer, architectural color, powder coat finish

    · High impact, heat resistant, tempered lens

    Energy Control Options

    · Motion detection available

    · Photo sensors availabl
